Airtac ACQ160 Slim Cylinder ACQ160X75SB
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X75SB Ultra-Thin Cylinder Specifications
- Model: ACQ160X75SB
- Type: Single-acting spring return (push type)
- Bore size: 160mm
- Stroke: 75mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Cushion type: Adjustable rubber cushion
- Port size: PT1/2 (G1/2 optional)
- Mounting style: Standard foot mounting (ISO 15552 compatible)
- Temperature range: -20℃ to 80℃
- Seal material: Polyurethane (PU) with wear-resistant ring
- Weight: 3.2kg (without accessories)
- Dimensions: 175mm(L) × 160mm(W) × 32mm(H)
- Piston speed: 50–800mm/s (lubricated)
- Protection rating: IP54 (standard wiper design)
Ultra-low profile cylinder featuring a 20% slimmer profile than standard models, optimized for space-constrained automation systems. The anodized aluminum construction with chromium-plated piston rod ensures corrosion resistance in humid environments. Includes built-in magnetic sensor slots (M9x1 connector compatible) for position feedback integration.
- High-density packaging line clamping mechanisms
- PCB handling robots in electronics manufacturing
- Automated warehouse vertical lift platforms
- Plastic injection molding ejection systems
- Solar panel cleaning apparatus articulation
Installation note:
Requires minimum 0.5mm alignment tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Avoid side load exceeding 30N during operation.
| Property | Property Value |
|---|---|
| sku | ACQ160X75SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 75mm |
