Airtac ACQD Double Acting Compact Cylinder ACQD100X10SB
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X10SB Double Rod Thin Cylinder Specifications
- Model: ACQD100X10SB
- Type: Double rod, compact series
- Bore size: Ø100mm
- Stroke: 10mm (customizable up to 300mm)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Piston rod diameter: Ø25mm (chromed steel)
- Max thrust: 706N at 0.7MPa
- Max speed: 500mm/s
- Port size: G3/8 (standard) or optional NPT1/2
- Ambient temperature: -20℃ to 80℃
- Seal material: Nitrile rubber (NBR) / optional Fluorocarbon (FKM)
- Weight: 2.5kg ±5% (without accessories)
- Dimensions: 156mm(L) × 100mm(W) × 100mm(H)
- Mounting options: Basic foot (MF1), front flange (MF2), rear flange (MF3)
- Accessories: Magnetic switch (D-A93 compatible), rod end fittings
Ultra-flat dual-rod pneumatic cylinder optimized for symmetrical force applications. Features hard anodized aluminum tube with integrated wear bands for maintenance-free operation. The T-slot design allows flexible sensor mounting. Optional corrosion-resistant versions available for food/pharma environments.
- Precision clamping in CNC tool changers
- Vertical lift mechanisms in semiconductor handling
- Synchronized gate control in packaging lines
- Press-fit operations in automotive assembly
- Parallel gripper configurations in robotics
Installation tip:
Maintain 0.5mm minimum clearance between rods during parallel mounting.
Use locknuts with 24-28Nm torque for rod-end connections. Lubricate with ISO VG32
hydraulic oil if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | ACQD100X10SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <10mm> |
