Airtac ACQD Double Acting Compact Cylinder ACQD100X125
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X125 Double Rod Compact Cylinder Specifications
- Model: ACQD100X125
- Series: ACQD Double Rod Slim Cylinder Series
- Bore Size: 100mm
- Stroke: 125mm
- Operating Pressure: 0.1–0.9 MPa
- Cushioning: Adjustable air cushion (both ends)
- Temperature Range: -20℃ to 80℃
- Mounting Style: Basic type (accessory brackets required)
- Port Size: G3/8 (ISO standard)
- Piston Rod Diameter: 25mm
- Repeat Positioning Accuracy: ±0.5mm
- Max Speed: 500mm/s
- Lubrication: Not required (pre-lubricated)
- Material:
- Cylinder Tube: Aluminum alloy with hard anodizing
- End Caps: Aluminum alloy
- Piston Rod: Stainless steel (SUS304)
- Seals: NBR (nitrile rubber)
- Weight: 4.5kg ±2% (excluding accessories)
- Dimensions: 298mm(L) × 100mm(W) × 100mm(H)
A space-optimized linear actuator featuring synchronized dual rod movement for balanced force distribution. The hard-anodized barrel and chromium-plated rods ensure corrosion resistance in humid environments. Its compact profile allows direct integration into machinery frames without bulky mounts.
- Precision alignment systems in semiconductor manufacturing
- Vertical lift mechanisms for warehouse automation
- Simultaneous clamping devices in automotive welding lines
- Parallel gate control in packaging machinery
- Position synchronization in LCD panel handling robots
Installation note:
Maintain ≤0.05mm perpendicularity tolerance during bracket mounting.
Use locknuts (M10×1.25 recommended) with 12-15Nm torque for rod-end loads.
For vertical operation, install speed controller valves to prevent piston free-fall.
| Property | Property Value |
|---|---|
| sku | ACQD100X125 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
