Airtac ACQD Double Acting Compact Cylinder ACQD100X125S
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X125S Double Rod Compact Cylinder Specifications
- Model: ACQD100X125S
- Type: Double rod thin-series pneumatic cylinder
- Bore size: Ø100 mm
- Stroke: 125 mm (customizable 25-300 mm)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: Rc1/4 (G1/4 optional)
- Piston rod diameter: Ø25 mm (hard chrome-plated)
- Material: Aluminum alloy barrel, CR/SEALS
- Mounting: Basic type (MF1) / Front flange (MF3) / Rear flange (MF2)
- Weight: 3.5 kg ±2%
- Dimensions: 298mm(L) × 122mm(W) × 122mm(H)
- ISO standard: 6431 (VDMA 24562)
Ultra-slim profile cylinder (30% thinner than standard models) with dual through-rods providing symmetrical force output and position detection readiness. Features wear-resistant guide bushings and multi-lip seals for ≤0.5mm/s leakage rate. Includes anti-rotation mechanism for precise linear motion.
- High-speed pick-and-place systems in electronics assembly
- Precision web tension control for printing presses
- Vertical lifting platforms with position feedback
- Clamping fixtures requiring dual-end force measurement
- Cleanroom-compatible automation equipment
Installation note:
Maintain 0.05-0.12mm clearance between rod and guide sleeve. Lubricate with ISO VG32 hydraulic oil.
Avoid side loads exceeding 30N. For vertical mounting, use counterbalance valves.
| Property | Property Value |
|---|---|
| sku | ACQD100X125S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
