Airtac ACQD Double Acting Compact Cylinder ACQD100X150B
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X150B Double Rod Compact Cylinder Specifications
- Model: ACQD100X150B
- Type: Double rod, thin series pneumatic cylinder
- Bore size: 100mm
- Stroke: 150mm (customizable 25-500mm)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-700mm/s
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting type: Basic fixed (MF1) with optional foot/flange mounting
- Port size: G3/8 (NPT1/2 optional)
- Ambient temperature: -20℃ to 80℃
- Piston material: High-strength aluminum alloy (Anodizing)
- Rod material: Chrome-plated stainless steel (SUS304)
- Seal type: NBR + PU hybrid seals
- Protection rating: IP54 (standard), IP67 optional
- Weight: 3.8kg ±5% (without accessories)
- Dimensions: 240mm(L) × 120mm(W) × 120mm(H)
- Repeat positioning accuracy: ±0.2mm
Ultra-flat profile cylinder (height only 12cm) designed for space-constrained automation systems. Features twin-rod stabilization for precise linear motion control and anti-rotation design. Integrated magnetic slot allows for sensor mounting. Operates in both horizontal/vertical orientations with ≤0.5mm/m alignment tolerance.
- PCB handling robots in electronics manufacturing
- Glass panel pressing mechanisms
- Automated packaging line gripper positioning
- Pharmaceutical tablet pressing machines
- Solar panel assembly jigs
Installation guidelines:
Lubricate rod surfaces with ISO VG32 hydraulic oil before initial use.
Maintain 1.5× bore size as minimum lateral clearance.
For vertical mounting, install air vent at upper port to prevent piston drift.
| Property | Property Value |
|---|---|
| sku | ACQD100X150B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 150mm |
