Airtac ACQD Double Acting Compact Cylinder ACQD100X15SB
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X15SB Double Rod Thin Cylinder Specifications
- Model: ACQD100X15SB
- Type: Double-acting, double rod thin series
- Bore size: Φ100mm
- Stroke: 15mm (standard), customizable up to 300mm
- Operating pressure: 0.05–1.0 MPa
- Operating medium: Clean air (40μm filtered)
- Ambient temperature: -20℃ to 80℃
- Cushion type: Adjustable buffer (both ends)
- Piston speed: 50–750 mm/s
- Mounting options: MF1/MF2 basic mounting, various flange/bracket options
- Rod material: Hard chrome-plated carbon steel
- Seal material: NBR/PU (standard), optional FKM
- Weight: 3.5kg (without accessories)
- Dimensions: 240mm(L) × 120mm(W) × 100mm(H)
- Port size: G3/8 (standard), optional NPT1/2
- Protection rating: IP65 (standard), IP67 optional
Ultra-compact twin-rod cylinder with symmetric force output, featuring 30% reduced axial length compared to standard models. Precision honed aluminum barrel with integrated magnet slot for position sensing. Designed for bi-directional equal thrust applications requiring space optimization.
- Simultaneous clamping in CNC fixture systems
- Precision alignment in semiconductor wafer handling
- Bilateral actuation in packaging sealing machines
- Space-constrained automation in robotics end effectors
- Parallel force applications in press brake tooling
Installation note:
Ensure proper rod alignment using alignment couplers when connecting to loads.
Lubricate with ISO VG32 hydraulic oil (air line lubricator recommended).
Maximum side load: 10% of rated thrust. For vertical mounting,
use counterbalance valves to prevent drift.
| Property | Property Value |
|---|---|
| sku | ACQD100X15SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <15mm> |
