Airtac ACQD Double Acting Compact Cylinder ACQD100X175B
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X175B Double Rod Thin Cylinder Specifications
- Model: ACQD100X175B
- Type: Double rod compact cylinder (ISO 6432 compliant)
- Bore size: 100mm
- Stroke: 175mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s (cushioned)
- Ambient temperature: -20℃ to 80℃
- Buffer type: Adjustable rubber cushion (both ends)
- Mounting style: Basic (optional flange/feet mounting)
- Port size: G3/8 (M14×1.5 thread)
- Cylinder tube material: Aluminum alloy hard anodized
- Piston rod material: Chrome-plated steel (Cr-Mo)
- Seal material: NBR + polyurethane (wear-resistant)
- Weight: 4.7kg (dry, without accessories)
- Dimensions:
- Length: 338mm (including rods)
- Width: 118mm (max. cross-section)
- Height: 100mm (barrel diameter)
- Rod diameter: 25mm (both ends)
- Protection rating: IP54 (standard), IP67 optional
Ultra-slim dual-action pneumatic cylinder optimized for space-constrained automation systems. Features synchronized dual rod movement for balanced force distribution (5.2kN thrust @0.6MPa). Precision ground rods with chrome plating ensure 2μm Ra surface roughness for minimal seal wear. Optional magnetic piston version (ACQD100X175B-M9) available for position sensing.
- Simultaneous clamping in CNC fixture systems
- Parallel lifting mechanisms in packaging lines
- Precision alignment in semiconductor wafer handling
- Synchronized door operation in cleanroom equipment
- Bilateral pressing in battery cell assembly
Installation tips:
Maintain ≤0.1mm/m alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
if operating below -10℃. Allow 20mm clearance behind rods for full stroke operation.
| Property | Property Value |
|---|---|
| sku | ACQD100X175B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 175mm |
