Airtac ACQD125 Double-rod Compact Cylinder ACQD125X100S
2. Features C-shaped retaining rings for cylinder body and end cover fixation, ensuring compact and reliable construction;
3. Precision-machined bore with hard anodized treatment for superior wear resistance and extended service life;
4. Special-shaped bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir functionality;
5. Space-saving design effectively minimizes installation footprint;
6. Pre-machined sensor grooves along cylinder periphery facilitate easy sensor mounting.
Category: Double Rod Cylinders, Brand: AIRTAC, Series: ACQD125
AirTAC ACQD125X100S Double Rod Thin Cylinder Specifications
- Model: ACQD125X100S
- Type: Double-acting compact cylinder with dual rod
- Bore size: 125mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Elastic buffer (adjustable end caps)
- Mounting style: Standard square base (MF12) with through-hole mounting
- Port size: G3/8 (BSPP thread)
- Piston rod thread: M16×1.5
- Tube material: Aluminum alloy with hard anodized surface
- Rod material: Chrome-plated carbon steel (S45C)
- Seal material: NBR (Nitrile rubber)
- Weight: 3.5kg ±2% (without accessories)
- Dimensions: 200mm(L) × 145mm(W) × 62mm(H) (at mid-stroke position)
- ISO standard: Compliant with ISO 6432 mounting dimensions
Ultra-slim profile cylinder (62mm height) designed for space-constrained automation systems. Features synchronized dual rod movement for balanced force transmission and precise linear motion. The through-rod design allows external position sensing and mechanical linkage. Corrosion-resistant construction with IP54 protection rating ensures reliability in humid environments.
- High-speed sorting arms in logistics systems
- Precision clamping devices in CNC tool changers
- Vertical lift mechanisms for LCD panel handling
- Synchronized gripping in packaging machinery
- Position adjustment in semiconductor wafer stages
Installation notes:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 30N.
For vertical mounting, use rod-down orientation to prevent seal wear from piston self-weight.
Maintain 0.3-1.0 MPa operating pressure for optimal cushioning performance.
| Property | Property Value |
|---|---|
| sku | ACQD125X100S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 100mm |
