Airtac ACQD140 Double Rod Compact Cylinder ACQD140X100SB
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X100SB Double Rod Compact Cylinder Specifications
- Full model: ACQD140X100SB
- Bore size: 140mm
- Stroke: 100mm
- Action type: Double rod, double acting
- Operating pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Port size: Rc1/4 (G1/4 optional)
- Rod diameter: 25mm
- Barrel material: Aluminum alloy hard anodized
- Piston rod material: Chrome-plated steel
- Seal material: NBR + Polyurethane
- Weight: 5.8kg (without accessories)
- Dimensions:
- Body width: 45mm
- Body height: 140mm (bore diameter)
- Total length: 226mm (basic length) + 100mm (stroke)
- Mounting type: Basic type (axial foot mounting holes)
- Protection rating: IP65
- Lubrication: Pre-lubricated (oil-free operation possible)
Ultra-flat profile cylinder (45mm width) with dual synchronized rods, engineered for precision alignment in space-constrained automation systems. Features symmetrical force output and position detection readiness through optional magnetic piston. Anti-rotation design maintains orientation stability during high-speed cycles (max 1.5 m/s).
- Precision press mechanisms in PCB assembly
- Parallel gripper actuation in robotic systems
- Vertical lifting platforms in packaging lines
- Clamping fixtures for CNC machine tooling
- Position synchronization in glass handling systems
Installation note:
Ensure lateral mounting surface flatness ≤0.2mm/m. For vertical installations,
use rod-down orientation to prevent condensate accumulation. Lubricate through
air supply (ISO VG32 recommended) if operating beyond 1 million cycles.
| Property | Property Value |
|---|---|
| sku | ACQD140X100SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 100mm |
