Airtac ACQD140 Double Rod Compact Cylinder ACQD140X125SB
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X125SB Double Rod Compact Cylinder Specifications
- Full model: ACQD140X125SB
- Bore size: Ø40mm
- Stroke: 125mm
- Operating pressure: 0.15–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: M5x0.8 (dual ports on both caps)
- Mounting type: Basic type (SB series) with standard foot mounting grooves
- Rod thread: M10x1.25 (both ends)
- Cylinder tube material: Aluminum alloy hard anodized
- Piston rod material: Stainless steel SUS304
- Seal material: NBR (Nitrile rubber)
- Weight: 1.8kg ±2% (without accessories)
- Dimensions: 249mm(L) × 51mm(W) × 56mm(H) (extended length)
- Minimum lateral load distance: 12mm from centerline
- Maximum theoretical force: 1134N @0.7MPa
Ultra-slim profile cylinder (56mm height) with dual rod configuration enables symmetrical force transmission and position detection on both ends. Features corrosion-resistant construction with chrome-plated piston rods and wear-resistant guide rings. Includes magnetic piston for sensor attachment (multiple mounting slots). Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms in semiconductor testers
- Vertical lift systems in medical bed adjustments
- Cartesian coordinate actuators for packaging lines
- Automatic door locking mechanisms in cleanrooms
Installation note:
Maintain 0.05mm maximum misalignment during mounting. Use rod-end bearings for
angular motion applications. Lubricate with ISO VG32 hydraulic oil before initial
operation. For vertical mounting, install air vents upward.
| Property | Property Value |
|---|---|
| sku | ACQD140X125SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 125mm |
