Airtac ACQD140 Double Rod Compact Cylinder ACQD140X200S
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X200S Double Rod Thin Cylinder Specifications
- Model: ACQD140X200S
- Type: Double-acting compact cylinder with dual rod
- Bore size: Ø140 mm
- Stroke: 200 mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Port size: G1/2 (ISO standard)
- Piston rod thread: M16×1.5 (both ends)
- Mounting type: Basic (axial mounting holes)
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 6.8 kg (±2%)
- Dimensions: 308mm(L) × 140mm(W) × 140mm(H)
- Repeat accuracy: ±0.5mm
- Max theoretical thrust: 12,348N (at 0.8MPa)
Ultra-flat profile cylinder (height/width ratio 1:1) designed for space-constrained applications requiring balanced bidirectional force. Features corrosion-resistant construction with built-in magnet for position sensing (S suffix version). Requires 5μm filtered lubricated air (ISO 8573-1 class 3-4-3).
- Automated clamping fixtures in CNC machining centers
- Precision alignment systems in semiconductor handling
- Parallel gripper mechanisms for robotic arms
- Vertical lifting platforms in packaging lines
- Press-fit operations in automotive assembly
Installation note:
Maintain 0.5mm minimum clearance between rod ends and load during alignment.
For vertical mounting, install air inlet at upper port to prevent condensate accumulation.
Lubricate through FRL unit at 1-2 drops/m³ airflow.
| Property | Property Value |
|---|---|
| sku | ACQD140X200S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | <200mm> |
