Airtac ACQD140 Double Rod Compact Cylinder ACQD140X250S
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X250S Double Rod Compact Cylinder Specifications
- Model: ACQD140X250S
- Bore size: Ø140 mm
- Stroke: 250 mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Square mounting holes with through slots
- Port size: PT1/2 (G1/2 optional)
- Piston rod thread: M20×1.5 (both ends)
- Material: Aluminum alloy body, hard anodized piston rod
- Seal material: NBR (standard)/PU (optional)
- Weight: Approximately 3.8 kg
- Dimensions: 380mm(L) × 142mm(W) × 142mm(H)
- Protection rating: IP54 (standard)/IP67 (wipers upgraded)
- Max theoretical thrust: 15,386N @1.0MPa
- Max speed: 500 mm/s
A space-optimized twin rod cylinder featuring symmetrical force output and minimal deflection. The reduced height profile (30% thinner than standard cylinders) enables installation in confined spaces. Precision-machined guide bands ensure smooth operation with ≤0.5mm lateral play. Includes anti-rotation design for stable load handling.
- Clamping fixtures in injection molding machines
- Parallel gate control in automated warehouses
- Press-fit operations in automotive assembly
- Web tensioning systems in printing equipment
- Position synchronization in material transfer systems
Installation guidance:
Maintain coaxial alignment within 0.2mm tolerance during mounting.
Lubricate rod ends with ISO VG32 hydraulic oil before initial operation.
For vertical installations, use rod-end supports to prevent buckling.
Critical note:
Avoid side load exceeding 200N. When used in high-cycle applications
(>5 cycles/sec), install external shock absorbers and monitor
rod temperature (max 70℃).
| Property | Property Value |
|---|---|
| sku | ACQD140X250S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | <250MM> → <250mm> |
