Airtac ACQD140 Double Rod Compact Cylinder ACQD140X300S
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X300S Double Rod Thin Cylinder Specifications
- Model: ACQD140X300S
- Type: Double-acting compact cylinder
- Bore size: Ø140mm
- Stroke: 300mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Ambient temperature: -20℃ to 80℃
- Mounting style: Basic type (multiple options available)
- Port size: Rc1/4 (NPT1/4 optional)
- Piston material: Aluminum alloy with hard anodization
- Rod material: SUS304 stainless steel
- Seal type: NBR seals (FKM optional)
- Weight: 6.5kg ±3% (without accessories)
- Dimensions: 300mm(Stroke) × 140mm(Bore) × 168mm(Height)
- Rod diameter: Ø25mm
- Max theoretical thrust: 1539N @0.63MPa
- ISO standard: 6432 compliant
Ultra-slim profile cylinder featuring dual rod synchronization and space-saving design (35% thinner than standard cylinders). Incorporates corrosion-resistant construction with precision honed tube and low-friction seals. Includes magnetic version option (ACQDM series) for position sensing. Requires 5μm filtered air with ISO 8573-1:2010 class 4.4.3.
- High-precision alignment in semiconductor handling systems
- Simultaneous clamping operations in CNC fixtures
- Compact packaging line pusher mechanisms
- Automated textile machinery tension control
- Parallel lifting platforms in logistics automation
Installation tip:
Maintain 0.5mm minimum lateral clearance during mounting. For vertical installations,
use rod-end locking nuts (specification AN7-M6). Lubricate through port with ISO VG32
oil before initial operation.
| Property | Property Value |
|---|---|
| sku | ACQD140X300S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 300mm |
