Airtac ACQD140 Double Rod Compact Cylinder ACQD140X30SB
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X30SB Double Rod Compact Cylinder Specifications
- Model: ACQD140X30SB
- Type: Double-acting, dual rod thin-series cylinder
- Bore size: Ø140 mm
- Stroke: 30 mm (customizable 10-300mm)
- Operating pressure: 0.15-0.8 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Rod diameter: Ø25 mm (chrome-plated steel)
- Port size: G3/8 (ISO standard)
- Mounting type: Standard foot mounting (SB series)
- Ambient temperature: -20℃ to +80℃
- Seal material: NBR (nitrile rubber)
- Weight: 3.8 kg (excluding accessories)
- Dimensions:
- Total length: 226 mm (L=30mm stroke)
- Body width: 155 mm (including mounting flanges)
- Height: 140 mm (bore diameter equivalent)
- Piston speed: 50-800 mm/s (lubricated)
- ISO standard: 6432 (compact cylinder specifications)
Ultra-slim profile cylinder (40% thinner than standard models) with symmetrical dual rod configuration for balanced force output. Features anodized aluminum body with integrated wear-resistant guides, designed for precision linear motion in space-constrained applications. Optional magnetic piston version (add "-M" suffix) for position sensing.
- High-density automation cells requiring parallel actuation
- Electronics manufacturing pick-and-place units
- Medical device clamping mechanisms
- Packaging machine lateral compression systems
- Automotive welding fixture positioning
Installation notes:
- Align rods perfectly parallel to prevent side load (max 0.05° angular misalignment)
- Use flexible couplings for stroke-end force absorption
- Lubricate with ISO VG32 hydraulic oil if non-lubricated air is used
- For vertical mounting, add 20% safety factor to load calculations
| Property | Property Value |
|---|---|
| sku | ACQD140X30SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 30mm |
