Airtac ACQD140 Double Rod Compact Cylinder ACQD140X50SB
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X50SB Double Rod Compact Cylinder Specifications
- Model: ACQD140X50SB
- Type: Double-acting, dual rod thin-series cylinder
- Bore size: Ø140mm
- Stroke: 50mm (customizable 25-300mm)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Port size: Rc1/4 (G1/4 optional)
- Mounting style: Basic type (optional flange/feet mounting)
- Cylinder tube material: Aluminum alloy with hard anodization
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Seal material: NBR (nitrile rubber) standard
- Weight: 3.8kg ±2% (without accessories)
- Dimensions:
- Total length (L): 214mm (50mm stroke)
- Body width (W): 156mm
- Height (H): 52mm
- Rod diameter: Ø25mm
- Rod thread: M12x1.75
- ISO standard: 15552 compliant
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil)
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features synchronized dual rod movement for balanced force distribution and precise linear motion control. The hard-anodized barrel resists wear in high-cycle applications (up to 2,000km service life). Includes magnetic piston for position sensing compatibility.
- High-speed sorting arms in logistics systems
- Precision glass panel pressing machines
- Semiconductor wafer handling robots
- Parallel gripper mechanisms
- Medical device assembly stations
- Food packaging line actuators
Installation tips:
Maintain 0.5-1mm clearance between rods during parallel mounting.
Use rod-end bearings for angular misalignment compensation.
Lubricate every 3 months under normal operation (500kPa).
| Property | Property Value |
|---|---|
| sku | ACQD140X50SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | <50mm> |
