Airtac ACQD140 Double Rod Compact Cylinder ACQD140X75S
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X75S Double Rod Thin Cylinder Specifications
- Model: ACQD140X75S
- Type: Double-acting compact cylinder with dual rod
- Bore size: Ø40mm (140 series)
- Stroke: 75mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting options: MF1/MF2/MF3 base mounts or foot mounting
- Port size: M5x0.8 (G1/8 adapter available)
- Piston rod material: Hard chrome-plated stainless steel (SUS304)
- Barrel material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Protection rating: IP54 (standard), IP67 (optional w/rod cover)
- Weight: 1.25kg (excluding accessories)
- Dimensions: 206mm(L) × 48mm(W) × 40mm(H) (full extension)
- Rod diameter: Ø12mm (dual rods)
- Max theoretical force: 125.6N @ 0.5MPa
Ultra-slim profile cylinder (18mm height reduction vs standard models) featuring symmetrical dual-rod design for balanced bidirectional force transmission. Incorporates wear-resistant guide bushings and low-friction seals, achieving ≤0.15mm repeat positioning accuracy. Requires ISO 8573-1:2010 Class 3 compressed air.
- Precision clamping in SMT pick-and-place machines
- Vertical lifting mechanisms in automated packaging lines
- Bidirectional actuation in semiconductor wafer handling
- Compact press systems for electronic component assembly
- Synchronized motion control in medical device manufacturing
Installation guidelines:
Maintain 0.5mm minimum clearance between rods during parallel installations.
Lubricate with ISO VG32 hydraulic oil (non-detergent) during commissioning.
Avoid side loads exceeding 15N·m. Horizontal mounting requires monthly rod wiper maintenance.
| Property | Property Value |
|---|---|
| sku | ACQD140X75S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 75mm |
