Airtac ACQD140 Double Rod Compact Cylinder ACQD140X75SB
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X75SB Double Rod Thin Cylinder Specifications
- Model: ACQD140X75SB
- Type: Double-acting double rod compact cylinder
- Bore size: 140mm
- Stroke: 75mm
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Rod material: Stainless steel (SUS304)
- Tube material: Hard anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Port size: G1/2 (ISO standard)
- Mounting type: Standard foot mounting (ISO 15552 compatible)
- Weight: 3.5kg ±2%
- Dimensions: 220mm(L) × 148mm(W) × 148mm(H)
- Protection rating: IP65 (standard wiper seal)
- Max piston speed: 0.1–1.5 m/s
- Theoretical output force: 13,846N at 0.63MPa
Ultra-flat profile cylinder with twin rod configuration designed for space-constrained applications requiring bidirectional force symmetry. Features precision honed tube and chrome-plated piston rods for extended service life. The integrated magnetic ring enables position sensing compatibility. Optional auto-switch grooves (M9x1.25) on both sides for sensor mounting.
- High-precision clamping fixtures in CNC machining centers
- Simultaneous lifting mechanisms in automated assembly lines
- Parallel gripper actuation in robotic systems
- Paper/web tension control in printing machinery
- Balanced force applications in glass handling equipment
Installation tip:
Maintain 0.5mm minimum clearance between rods and adjacent components.
Lubricate with ISO VG32 hydraulic oil during initial setup. Avoid lateral
loads exceeding 30N to prevent rod bending. For vertical mounting,
install lock nut (accessory code: LN-14) to prevent gravity-driven drift.
| Property | Property Value |
|---|---|
| sku | ACQD140X75SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 75mm |
