Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X20-20S
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X20-20S Adjustable Compact Cylinder Specifications
- Model Series: ACQJ12~25 (12mm/16mm/20mm/25mm bore sizes)
- Specific Model: ACQJ12X20-20S
- Bore Diameter: 12mm
- Stroke: 20mm
- Mounting Type: Front flange with single mounting hole (S-type)
- Operating Pressure: 0.05~0.9 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Port Size: M5x0.8 (standard) with 1/8 NPT optional
- Piston Material: Aluminum alloy with hard anodization
- Rod Material: Stainless steel (SUS304)
- Seal Type: NBR seals with wear-resistant ring
- Weight: 0.13kg (without accessories)
- Dimensions:
- Length: 50mm (including cushion adjustment screws)
- Width: 30mm (flange mounting surface)
- Height: 22mm (body thickness)
- ISO Standard: Compliant with ISO 6432 (mounting dimensions)
Ultra-slim pneumatic cylinder featuring a 20% reduced height profile compared to standard models. The built-in stroke adjustment mechanism allows ±2mm fine-tuning via hex wrench. Corrosion-resistant design with IP54 protection rating ensures reliable operation in humid environments. Requires 5μm filtered air with ISO 8573-1:2010 Class 3 air quality.
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in CNC tool changers
- Compact actuator for medical diagnostic equipment
- Automatic paper feed systems in printers/copiers
- Space-constrained packaging machine ejectors
Installation note:
Maximum side load 3N. Use guided mounting when lateral forces exceed limit.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | ACQJ12X20-20S |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
