Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X20-20SB
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X20-20SB Adjustable Compact Cylinder Specifications
- Series: ACQJ12~25 (12mm-25mm bore sizes)
- Model: ACQJ12X20-20SB
- Bore size: 12mm
- Stroke: 20mm
- Action type: Double-acting
- Operating pressure: 0.05~0.8 MPa
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (no built-in mount)
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Temperature range: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.14kg (excluding accessories)
- Dimensions:
- Length: 56mm (cylinder body) + stroke
- Width: 32mm (max profile width)
- Height: 20mm (body thickness)
- ISO standard: 6432 (compact cylinder specifications)
- Corrosion resistance: Class II (standard industrial use)
Ultra-slim profile cylinder with space-saving design (20mm thickness) featuring precision-machined guide grooves for stable linear motion. The dual adjustable air cushions minimize end-impact noise while allowing precise stroke adjustment (±0.5mm). Pre-lubricated for maintenance-free operation with integrated wiper seal preventing contaminant ingress.
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms in optical lens production
- Valve actuation in medical analyzers
- Paper feed systems in compact printers
- Automated sorting gates in logistics equipment
Installation tip:
Use precision alignment tools during mounting - maximum allowable
lateral load is 1.5N. For vertical installations, add a stroke-end
locking mechanism to prevent unintended movement during power loss.
| Property | Property Value |
|---|---|
| sku | ACQJ12X20-20SB |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
