Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X25-10S
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X25-10S Adjustable Compact Cylinder Specifications
- Series: ACQJ12~25 (12mm-25mm bore size range)
- Full model: ACQJ12X25-10S
- Bore size: 12mm
- Stroke: 25mm (adjustable through cushion mechanism)
- Operating pressure: 0.05~0.8 MPa
- Buffer type: Adjustable rubber cushion
- Port size: M5x0.8 (ISO G1/8 optional)
- Temperature range: -20℃ to 80℃
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR
- Mounting type: Standard foot + axial accessory holes
- Protection rating: IP40 (dust-proof)
- Weight: 0.23kg ±5%
- Dimensions:
- Length (stroke extended): 97mm
- Width: 30mm
- Height: 30mm
- Base mounting hole spacing: 25mm × 12mm
Ultra-slim profile cylinder (30mm height) with stroke adjustment mechanism, featuring a 360° rotatable piston rod for flexible installation. The dual-shaft design enhances lateral load capacity while maintaining compactness. Includes built-in magnetic ring for sensor mounting (D-M9N series compatible). Lubrication-free operation with wear-resistant guide bushing.
- PCB board clamping in SMT machines
- Precision positioning in semiconductor handlers
- Component ejection in micro-molding systems
- Miniature workpiece transfer in watch assembly
- Valve actuation in portable medical devices
Installation note:
Use Cushion Locknut (ASNU5) for stroke adjustment - turn clockwise to shorten stroke.
Max lateral load: 3N at full extension. Recommend using with ARJ6 series joints for
angular misalignment compensation.
| Property | Property Value |
|---|---|
| sku | ACQJ12X25-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
