Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X25-10SB
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X25-10SB Adjustable Compact Cylinder Specifications
- Model Series: ACQJ12~25 (12mm/16mm/20mm/25mm bore options)
- Exact Model: ACQJ12X25-10SB
- Bore Size: 12mm
- Stroke: 25mm (adjustable stroke via built-in stopper)
- Mounting Type: Female threaded (M5x0.8) with through-hole design
- Operating Pressure: 0.05–0.9 MPa
- Temperature Range: -10℃ to 70℃ (NBR seals)
- Cushion Type: External adjustable rubber buffer
- Port Size: M5x0.8 (G1/8 adaptor optional)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Weight: 0.23kg (with standard accessories)
- Dimensions:
- Length: 102mm (fully retracted)
- Width: 30mm (mounting face to rod end)
- Height: 32mm (including cushion adjustment screws)
- Rod Thread: M6x1.0 male thread
- Max Speed: 500mm/s
- Lubrication: Pre-lubricated (Grease-free operation)
Ultra-slim pneumatic cylinder (only 32mm height profile) featuring position-sensitive cushioning adjustment via dual 2mm hex keys. The anodized body resists industrial corrosion while the 0.5μm chrome-plated rod minimizes wear. Includes anti-rotation guide slots for precise linear motion in confined spaces. Requires 40μm filtered air with <0.1mg/m³ oil content.
- PCB handling robots in electronics manufacturing
- Dosing valve actuators in pharmaceutical packaging
- Paper feed mechanisms for high-speed printers
- Clamping fixtures for CNC machine tooling
- Ventilation damper control in cleanrooms
Installation tip:
For vertical mounting, use counterbalance valves to prevent free fall.
Cushion adjustment should be performed at 80% of maximum operating pressure.
Avoid side loads exceeding 2N·m on piston rod.
| Property | Property Value |
|---|---|
| sku | ACQJ12X25-10SB |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
