Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X25-20B
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X25-20B Adjustable Compact Cylinder Specifications
- Model Series: ACQJ12~25 (12mm/16mm/20mm/25mm bore sizes)
- Full Model Code: ACQJ12X25-20B
- Bore Size: 12mm
- Stroke: 25mm (adjustable with stopper)
- Operating Pressure: 0.05–0.9 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (dual-side)
- Port Size: M5x0.8 (G1/8 optional)
- Mounting Type: Basic foot mounting (ISO 15552 standard compatible)
- Piston Material: Aluminum alloy with hard anodizing
- Rod Material: Stainless steel (SUS304)
- Seal Material: NBR (Nitrile rubber)
- Weight: 0.32kg ±5%
- Dimensions:
- Total Length (extended): 93mm
- Body Width: 34mm
- Height (with foot mount): 48mm
- Mounting Hole Spacing: 20mm (longitudinal) × 16mm (transverse)
- Sensor Compatibility: Built-in magnet for proximity switch (D-A93 series)
- Protection Rating: IP67 (dust/water resistant)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if maintained)
Ultra-slim profile cylinder (34mm width) with precision stroke adjustment mechanism, featuring dual-position locking screws for stroke stabilization. The corrosion-resistant design includes stainless steel piston rod and IP67 protection, making it ideal for cleanroom and outdoor applications. Optional auto switch grooves allow flexible sensor mounting.
- PCB handling robots in electronics manufacturing
- Precision clamping in optical lens assembly
- Valve actuation in pharmaceutical blister packaging
- Conveyor gate control in food processing lines
- Stage positioning in automated microscopy systems
Installation Tips:
For vertical mounting, use anti-vibration washers on foot mounts.
Maximum side load: 3N. Adjust cushion screws clockwise to decrease
terminal velocity. Lubricate every 3 million cycles in high-duty applications.
| Property | Property Value |
|---|---|
| sku | ACQJ12X25-20B |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
