Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X25-20S
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X25-20S Adjustable Compact Cylinder Specifications
- Model: ACQJ12X25-20S (ACQJ Series 12-25mm)
- Type: Single-acting spring return (air to extend)
- Bore size: 12mm (standard series)
- Stroke: 25mm (adjustable via external stoppers)
- Operating pressure: 0.15–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper
- Port size: M5x0.8 (1/8" NPT optional)
- Mounting: 20mm center-to-center dual mounting holes (ISO 6432 standard)
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile) standard
- Piston rod material: Stainless steel SUS304
- Weight: 0.28kg (with accessories)
- Dimensions: 65mm(L) × 32mm(W) × 32mm(H) (at full extension)
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (relubrication interval: 2,000km)
Ultra-slim profile cylinder (only 32mm cross-section) with external stroke adjustment screws for precision positioning. Features dual anti-rotation guide slots (180° apart) and IP54-rated ingress protection. The low-friction design achieves ≥90% theoretical efficiency at 0.5MPa. Requires 40μm filtered air with ISO VG32 hydraulic oil mist lubrication for optimal performance.
- PCB handling robots in electronics assembly
- Medical device component positioning systems
- Automated door locking mechanisms
- Textile machinery thread tension control
- Semiconductor wafer transfer units
Installation note:
Maximum side load 5N. Use 0.1-0.3mm shim washers when mounting
to uneven surfaces. Align piston rod within 0.5° angular deviation.
| Property | Property Value |
|---|---|
| sku | ACQJ12X25-20S |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
