Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X25-20SB
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X25-20SB Adjustable Compact Cylinder Specifications
- Series: ACQJ12~25 (12mm-25mm bore size range)
- Full model: ACQJ12X25-20SB
- Bore size: 12mm
- Stroke: 20mm (adjustable with ±0.5mm precision)
- Mounting type: Compact square body with through-hole design
- Operating pressure: 0.05~0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston material: Aluminum alloy with hard anodizing
- Rod material: SUS304 stainless steel
- Seal type: NBR rubber (oil-resistant)
- Weight: 0.18kg (without accessories)
- Dimensions: 50mm(L) × 34mm(W) × 34mm(H)
- Stroke tolerance: +1.5mm
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (DIN standard VDL oil)
Ultra-slim profile cylinder (20% thinner than standard models) with precision stroke adjustment capability. Features dual adjustable cushions for smooth end-of-stroke deceleration and impact reduction. The anti-rotation rod design ensures stable linear motion, while the stainless steel piston rod provides corrosion resistance in humid environments.
- High-density automation equipment layouts
- Precision positioning in SMT pick-and-place machines
- Compact medical device actuators
- Electronics assembly line clamping mechanisms
- Space-constrained packaging machinery
Installation tip:
Use alignment jigs during mounting to prevent side load. For vertical installations,
add a 0.3-0.5mm shim between mounting surfaces to compensate for thermal expansion.
Lubricate every 5 million cycles under normal operation.
| Property | Property Value |
|---|---|
| sku | ACQJ12X25-20SB |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
