Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X25-30
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X25-30 Adjustable Compact Cylinder Specifications
- Series: ACQJ12~25 (Compact Adjustable Stroke)
- Full model: ACQJ12X25-30
- Bore size: 12mm (ACQJ12)
- Stroke: 25mm (adjustable via built-in stroke limiter)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (dual-side)
- Mounting style: Basic type (optional foot/mid-flange mounts)
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seal type: NBR + special low-friction rings
- Repeat positioning accuracy: ±0.2mm
- Weight: 0.25kg (without accessories)
- Dimensions: 50mm(L) × 34mm(W) × 30mm(H) (body only)
- Full extended length: 82mm (25mm stroke)
Ultra-slim profile cylinder (30mm height) with stroke adjustment screws for precision positioning. Features corrosion-resistant construction with integrated magnet for sensor compatibility. Optimized for high cycle rates (up to 5Hz) and low air consumption (0.15L/min at 0.5MPa). Includes auto-lubrication design for maintenance-free operation.
- PCB handling robots in electronics assembly
- Medical device component positioning
- Bottle cap pressing mechanisms in packaging lines
- Precision valve actuation in analytical instruments
- Space-constrained automation in automotive welding jigs
Installation tip:
For vertical mounting, maintain ≤0.5mm alignment tolerance. Use anti-rotation brackets
when combining multiple cylinders. Lubricate through port with ISO VG32 oil if operating
below -10℃.
| Property | Property Value |
|---|---|
| sku | ACQJ12X25-30 |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
