Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X25-30B
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X25-30B Adjustable Compact Cylinder Technical Details
- Series: ACQJ12~25 (Thin-line adjustable series)
- Full model code: ACQJ12X25-30B
- Bore size: 12mm (0.47")
- Stroke: 25mm (0.98")
- Operating pressure: 0.05-0.9 MPa (7-130 PSI)
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (dual-side)
- Mounting type: Basic type (30B code = rectangular base with single mounting hole)
- Port size: M5x0.8 (standard) with G1/8 adaptor option
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seals: NBR standard (Polyurethane optional for high-speed apps)
- Weight: 0.22kg (0.485 lbs)
- Dimensions:
- Length (stroke extended): 75mm (2.95")
- Width: 34mm (1.34")
- Height: 22mm (0.87") at barrel section
- Base plate size: 20x12mm
- ISO compatibility: Compliant with ISO 6432 standards
Ultra-slim profile cylinder featuring position-adjustable stroke mechanism via external locknuts. The 30B variant's reinforced base plate enables vibration-resistant mounting in confined spaces. Includes wear-resistant guide bushings for lateral force compensation (max 1.5N·m). Requires 5μm filtered air with 1-2 drops of ISO VG32 oil per m³.
- PCB component insertion machines requiring precise end-position tuning
- Medical device lid clamping mechanisms
- Robotic end-effector tool changers
- High-cycle sorting gates in packaging lines
- Semiconductor wafer handling systems
Pro tip:
For vertical installations exceeding 0.5m/s speed, install an external shock absorber.
Lubricate rod wiper monthly in dusty environments using silicone-free grease.
| Property | Property Value |
|---|---|
| sku | ACQJ12X25-30B |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
