Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X25-30S
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X25-30S Adjustable Compact Cylinder Specifications
- Model Series: ACQJ12~25 (ACQJ12X25-30S as specific variant)
- Type: Double-acting adjustable stroke thin cylinder
- Bore size: 12mm (Standard series includes 12/16/20/25mm)
- Stroke: 25mm (Adjustable via built-in stroke limiter)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper (front/rear)
- Mounting type: 30S indicates female threaded rod end (M5x0.8)
- Port size: M5 (1/8") with NPT optional
- Piston material: Aluminum alloy with hard anodizing
- Rod material: SUS304 stainless steel
- Seal type: NBR seals for general use (FKM optional)
- Weight: 0.32kg ±2% (without accessories)
- Dimensions: 80mm(L) × 24mm(W) × 24mm(H) (Cylinder body only)
- Full extended length: 105mm (25mm stroke + end caps)
- Repeat accuracy: ±0.1mm (Under rated pressure)
- ISO standard: Compliant with ISO 6432 (8mm~25mm bore series)
Ultra-slim profile cylinder (24mm height) with integrated stroke adjustment screws, designed for precision positioning in confined spaces. Features corrosion-resistant construction and dual cushioning control. Optional auto switch grooves (M5 slot) for sensor mounting. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Precision clamping in CNC tool changers
- Label positioning systems in packaging lines
- Semiconductor wafer transfer equipment
Installation tip:
For vertical mounting, reduce operating pressure by 20% to compensate for self-weight.
Use locking nuts on adjustment screws after stroke setting. Lubricate every 500km stroke
travel with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | ACQJ12X25-30S |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
