Airtac ACQJ12~25 Adjustable Compact Cylinder ACQJ12X25-30SB
2. Features C-shaped retaining ring assembly for cylinder body and end caps, paired with a swaged piston-rod connection for compact reliability;
3. Precision honed inner bore ensures exceptional wear resistance and extended service life;
4. Optimized front end cap with elongated guide track enhances alignment stability;
5. Space-efficient profile minimizes installation footprint;
6. Integrated sensor grooves along cylinder periphery enable seamless magnetic switch integration;
7. Versatile mounting brackets and accessories available for multiple configurations;
Category: Slim Cylinder Series | Brand: AIRTAC | Model Range: ACQJ12~25
AirTAC ACQJ12X25-30SB Adjustable Compact Cylinder Specifications
- Model Series: ACQJ12~25 series
- Full Model: ACQJ12X25-30SB
- Type: Adjustable stroke thin cylinder (double-acting)
- Bore size: 12mm (0.47")
- Stroke: 25mm (1.0") with ±5mm adjustable stroke range
- Mounting: Basic type with through hole mounting
- Operating pressure: 0.05-0.9 MPa (7-130 PSI)
- Cushioning: Adjustable air cushion (both ends)
- Port size: M5x0.8 (standard)
- Piston rod thread: M5x0.8 (external)
- Material: Aluminum alloy body, NBR seals
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Protection rating: IP54 (standard)
- Weight: 0.18 kg (0.4 lbs)
- Dimensions:
- Length: 76mm (3.0")
- Width: 30mm (1.18")
- Height: 30mm (1.18")
Ultra-slim profile cylinder featuring external stroke adjustment screws for precise position control (±0.5mm repeatability). The 30SB variant includes built-in magnetic sensor slots for position feedback. Anti-rotation design maintains orientation stability during operation. Requires filtered lubricated air (ISO 8573-1 class 4.4.3) with 1-5 cSt oil viscosity.
- PCB component insertion machines
- Printing press gripper mechanisms
- Medical device positioning stages
- Packaging machine gate controls
- Semiconductor wafer handling
Installation note:
Use vibration-resistant locknuts (M5) for mounting. For vertical installations,
maintain 0.5-1mm gap between cylinder and stopper plate. Lubricate rod with
ISO VG32 hydraulic oil monthly in high-cycle applications (＞5 million cycles/year).
| Property | Property Value |
|---|---|
| sku | ACQJ12X25-30SB |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
