Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X10-10
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X10-10 Adjustable Compact Cylinder Specifications
- Series: ACQJ50~63
- Model: ACQJ50X10-10
- Bore size: 50mm
- Stroke: 10mm (adjustable ±2mm via external stopper)
- Operating pressure: 0.05–0.9 MPa
- Port size: G1/8 (M5 available as option)
- Cushioning: Adjustable rubber buffer
- Mounting type: Basic (axial mounting holes)
- Temperature range: -20℃ to 80℃
- Cylinder material: Anodized aluminum alloy
- Piston rod material: Chrome-plated steel
- Seal material: NBR (nitrile rubber)
- Weight: 0.82kg (without accessories)
- Dimensions:
- Body length: 106mm
- Total length (stroke extended): 116mm
- Width (including ports): 76mm
- Height (mounting surface to top): 50mm
- Optional accessories: Magnetic switch (D-A93), rod-end fittings
Ultra-slim profile cylinder (30% thinner than standard models) with external stroke adjustment capability. Features dual-side adjustable cushioning for precise end-position control and reduced impact noise. Integrated mounting grooves allow direct installation without additional brackets. The wear-resistant chromium piston rod maintains stable operation for >2,000km travel life.
- PCB handling robots in electronics manufacturing
- Precision clamping in CNC fixture systems
- Label positioning mechanisms in packaging lines
- Medical device actuation assemblies
- Solar panel cleaning equipment actuators
Installation note:
For optimal performance, maintain 0.5-1mm clearance between stopper and cylinder body during adjustment. Lubricate with ISO VG32 hydraulic oil if operating below 0.3MPa. Avoid side-load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | ACQJ50X10-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <10mm> |
