Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-10
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-10 Adjustable Compact Cylinder Specifications
- Series: ACQJ50~63 Thin-Type Cylinder Family
- Bore size: 50mm (Standard sizes: 50/63mm)
- Stroke: 100mm (Customizable: 10-300mm)
- Operation type: Double-acting with adjustable cushioning
- Working pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion adjustment: 360° rotatable screw type
- Mounting style: Basic type (MF1) with axial mounting holes
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Piston rod material: Stainless steel SUS304
- Tube material: Aluminum alloy hard oxidation
- Seal material: Heat-resistant NBR (-20℃~120℃)
- Weight: 1.85kg ±2% (Without accessories)
- Dimensions:
- Body length: 166mm (Min. compact length)
- Stroke length: 100mm
- Total width: 63mm (Including cushion screws)
- Height: 50mm (Bore diameter)
Ultra-slim profile cylinder (30% thinner than standard models) featuring dual adjustable rubber buffers for precise stroke-end control. The anodized body resists corrosion in humid environments, while the chromium-plated piston rod ensures smooth operation. Includes built-in magnet for position sensing compatibility.
- High-speed pick-and-place robots (cycle time ≤0.5s)
- Semiconductor wafer handling equipment
- Medical device assembly lines requiring ISO Class 5 cleanliness
- Overhead shuttle systems in warehouse automation
- Compact jig clamping mechanisms
Installation tips:
Use anti-vibration washers when mounting on aluminum frames.
Lubricate through port with ISO VG32 oil if operating below 0.3MPa.
Max lateral load: 35N at full extension.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
