Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-100
$82.31
Regular price
$89.81
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQJ50X100-100
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQJ50~63 Adjustable Compact Cylinder
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
Operation guidance:
Rotate the stroke adjustment nut clockwise to decrease stroke length (max 2 full turns).
Apply thread-locking adhesive after adjustment. Lubricate with ISO VG32 turbine oil
through built-in grease fittings every 500km of cumulative travel.
Critical note:
Do not exceed 1.2MPa momentary pressure. Avoid side-load forces >100N.
For vertical mounting, use guided carriage kits (optional accessory AMCQJ50).
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50~63 Adjustable Thin Cylinder ACQJ50X100-100 Technical Details
- Series: ACQJ (Compact Adjustable Stroke)
- Bore size: 50mm (Standard series: 50/63mm)
- Stroke: 100mm (Adjustable range: 0-100mm)
- Type: Double-acting cylinder with cushion
- Port size: G1/8 (NPT1/8 optional)
- Operating pressure: 0.05~1.0 MPa
- Piston speed: 50~800 mm/s
- Cushion type: Fixed rubber buffer + external adjustment
- Mounting style: Basic type (MF1) with multiple mounting holes
- Ambient temperature: -20℃ to 80℃
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Rod material: Stainless steel SUS304
- Weight: 1.35kg (excluding accessories)
- Dimensions:
- Body length: 196mm (minimum retracted length)
- Stroke adjustment range: 0-100mm
- Mounting hole spacing: 67mm (vertical) × 40mm (horizontal)
- Rod end thread: M10×1.25
Ultra-slim profile cylinder (25% thinner than standard models) with stroke adjustment locknut mechanism. Features dual-position sensing slots (T-slot and U-slot) for flexible sensor mounting. Anti-rotation design maintains precise end position accuracy (±0.5mm repeatability).
Industrial Applications:
- PCB handling robots requiring precision positioning
- Automated food packaging lines with space constraints
- Semiconductor wafer transfer mechanisms
- Medical device assembly with cleanroom requirements
- Printing press paper feed systems
Operation guidance:
Rotate the stroke adjustment nut clockwise to decrease stroke length (max 2 full turns).
Apply thread-locking adhesive after adjustment. Lubricate with ISO VG32 turbine oil
through built-in grease fittings every 500km of cumulative travel.
Critical note:
Do not exceed 1.2MPa momentary pressure. Avoid side-load forces >100N.
For vertical mounting, use guided carriage kits (optional accessory AMCQJ50).
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-100 |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
