Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-100S
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-100S Adjustable Compact Cylinder Specifications
- Series: ACQJ50~63 (50mm-63mm bore size range)
- Model: ACQJ50X100-100S
- Type: Double-acting adjustable thin-type cylinder
- Bore size: 50mm
- Stroke: 100mm (adjustable stroke mechanism)
- Mounting style: Standard square base with front flange
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/8 (NPT1/4 optional)
- Operating temperature: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodization
- Rod material: Chrome-plated carbon steel
- Seal type: NBR rubber seals (FKM available on request)
- Weight: 1.45kg ±2% (without accessories)
- Dimensions:
- Body length: 163mm (excluding rod)
- Extended length: 263mm (full stroke)
- Width: 60mm (mounting base)
- Height: 50mm (profile height)
- Protection class: IP54 (standard), IP67 optional
- Optional accessories: Magnetic switch (D-M9NW), rod lock kit
Ultra-slim profile cylinder with precision stroke adjustment mechanism, featuring dual-position stroke setting capability through its unique external adjustment screws. The 100S variant includes pre-drilled sensor mounting slots and enhanced rod bearing design for high lateral load resistance. Optimized for space-constrained applications requiring repeatable positioning accuracy.
- PCB handling robots in electronics assembly
- Clamping mechanisms in CNC tool changers
- Vertical lift systems in packaging machinery
- Precision paper feeding in printing equipment
- Medical device actuation systems
Installation note:
For optimal performance, maintain ≤0.5mm alignment tolerance during mounting. Lubricate with ISO VG32 turbine oil before initial use. Adjust cushion screws in 1/4-turn increments during commissioning. Avoid side load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-100S |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
