Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-100SB
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50~63 Adjustable Compact Cylinder ACQJ50X100-100SB Specifications
- Model Series: ACQJ50~63 (50mm/63mm bore sizes)
- Specific Model: ACQJ50X100-100SB
- Bore Size: 50mm
- Stroke: 100mm (adjustable through built-in stroke adjustment mechanism)
- Operating Pressure: 0.05~0.9 MPa
- Temperature Range: -20℃ to 80℃
- Cushion Type: Adjustable rubber cushion (both ends)
- Port Size: M5x0.8 (standard) or NPT1/8 (optional)
- Mounting Type: Basic foot mounting (SB suffix indicates reinforced base)
- Rod Thread: M10x1.25 (external)
- Piston Material: Aluminum alloy with hard anodized surface
- Seal Material: NBR (Nitrile) for standard temperature, optional FKM (Viton)
- Weight: 1.65kg ±2% (without accessories)
- Dimensions:
- Length: 180mm (full extension)
- Width: 60mm (mounting base span)
- Height: 50mm (cylinder body diameter)
- ISO Standard: Compliant with ISO 6432 (mounting dimensions)
- Repeat Positioning Accuracy: ±0.5mm
Ultra-slim profile cylinder (40% thinner than standard models) with dual-position stroke adjustment via external screw mechanism. Features anti-rotation guide slots and corrosion-resistant construction. The -100SB variant includes reinforced mounting lugs for high moment load applications. Requires filtered lubricated air (ISO 8573-1 class 3.4.2).
- PCB handling robots in electronics assembly
- Precision clamping in CNC tool changers
- Vertical lift mechanisms in packaging lines
- Medical device positioning systems
- Solar panel alignment actuators
Installation tip:
When using stroke adjustment, limit maximum extension to 95% of nominal stroke.
Apply thread locker (medium strength) to adjustment screws in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-100SB |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
