Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-10B
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-10B Adjustable Thin Cylinder Specifications
- Series: ACQJ50~63 (Compact Adjustable Series)
- Bore size: 50mm (Standard Sizes: 50/63mm)
- Stroke: 100mm (Adjustable Range: ±2mm via external screw)
- Operating pressure: 0.05~1.0 MPa
- Cushioning: Air cushion adjustable (with shock absorber)
- Mounting type: Basic type (Standard ISO 15552 foot mounting optional)
- Port size: M5x0.8 (Rc1/8/NPT1/8 adapters available)
- Operating temperature: -10℃ to 80℃
- Piston material: Die-cast aluminum alloy (hard anodized)
- Rod material: Chrome-plated stainless steel (SUS304)
- Seal material: Heat-resistant NBR (Nitril rubber)
- Weight: 1.45kg (Without accessories)
- Dimensions:
- Body length: 154mm (Minimum extended length)
- Stroke length: 100mm
- Width: 63mm (Mounting base width)
- Height: 50mm (Cylinder diameter)
- ISO standard: 6432 compliant (Compact cylinder specifications)
Ultra-slim profile cylinder featuring external stroke adjustment mechanism with ±2mm fine-tuning capability. The corrosion-resistant design integrates a built-in shock absorber for high-speed applications (max 1,000mm/s). Optimized for horizontal mounting with reinforced guide bearings. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- PCB handling robots in electronics assembly
- Precision clamping devices for CNC tooling
- High-cycle packaging machine actuators
- Medical device positioning mechanisms
- Automated conveyor sorting gates
Maintenance tip:
Apply ISO VG32 hydraulic oil mist lubrication monthly. Avoid lateral
force exceeding 30N during operation. For vertical installations,
use model with magnetic piston (add "-M" suffix).
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-10B |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
