Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-10S
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-10S Adjustable Compact Cylinder Specifications
- Series: ACQJ50~63 (Standard ISO 6432 compliant)
- Bore size: 50mm (1.97")
- Stroke: 100mm (3.94")
- Mounting type: Standard MF1/MF2 flange & foot mounting
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: M5x0.8 (G1/8 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum barrel, CR12MoV piston rod
- Seal type: NBR + PTFE hybrid seals
- Protection class: IP65 (standard rod wiper)
- Weight: 2.45kg (5.4 lbs)
- Dimensions: 200mm(L) × 63mm(W) × 63mm(H)
Ultra-slim profile cylinder (only 63mm cross-section) with 0.1mm precision stroke adjustment via dual locknuts. Features corrosion-resistant hard chrome piston rod (Rockwell HRC45-50) and anti-rotation guide mechanism. Requires ISO 8573-1 class 3 compressed air (40μm filtration recommended).
- PCB handling robots in electronics manufacturing
- Precision clamping in CNC tool changers
- High-density packaging line actuators
- Medical device assembly with space constraints
- Vertical lifting mechanisms under 50kg load
Installation tip:
For vertical mounting, use Cushion Lock (CL) version to prevent stroke creep.
Lubricate via port M5x0.8 with ISO VG32 pneumatic oil if cycle rate exceeds 3Hz.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
