Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-10SB
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-10SB Adjustable Compact Cylinder Specifications
- Series: ACQJ50~63 (50mm/63mm bore options)
- Full model: ACQJ50X100-10SB
- Bore size: 50mm
- Stroke: 100mm (adjustable stroke mechanism)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: External adjustable rubber buffers (both ends)
- Port size: M5x0.8 (dual ports)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel
- Seal type: NBR seals (-20℃ to 80℃)
- Mounting style: Front flange & rear foot combo
- Weight: 1.8kg ±5% (without accessories)
- Dimensions:
- Length: 215mm (full extension)
- Width: 68mm (mounting flange span)
- Height: 50mm (body thickness)
- Accessories: Includes magnetic switch slot (sensor-ready)
Ultra-slim profile cylinder featuring dual-action adjustable cushioning and integrated mounting system. The chrome-plated piston rod resists side loads up to 15% of maximum thrust capacity (300N @ 0.5MPa). Maintenance-free design with dust-resistant scraper ring. Requires 40μm filtered air with lubrication (ISO VG32 recommended).
- High-speed pick-and-place robots in electronics assembly
- Clamping fixtures for CNC machine tooling
- Vertical actuation in packaging line diverters
- Pressurization mechanisms in plastic injection molds
- Medical device testing equipment actuators
Installation tip:
Align cylinder axis within 0.2mm parallel tolerance to prevent binding.
For vertical mounting, use counterbalance valves when handling loads >5kg.
Buffer adjustment requires 2mm hex key (clockwise for softer end cushion).
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-10SB |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
