Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-20B
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50~63 Adjustable Compact Cylinder ACQJ50X100-20B Technical Details
- Series: ACQJ (Thin-type Adjustable Cylinder)
- Bore size: 50mm (also available: 63mm in ACQJ63 models)
- Stroke: 100mm (customizable from 25-300mm)
- Operating pressure: 0.05-1.0 MPa
- Buffer type: Adjustable rubber cushion (both ends)
- Mounting style: Basic type (20B code: square body with axial mounting holes)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Piston speed: 50-750 mm/s
- Ambient temperature: -20℃ to 80℃
- Cylinder material: Aluminum alloy (anodized surface)
- Rod material: Stainless steel (SUS304)
- Seal type: Nitrile rubber (NBR) with wear-resistant ring
- Protection class: IP54 (standard dust/moisture resistance)
- Weight: 1.35 kg (including mounting accessories)
- Dimensions:
- Length: 178mm (cylinder body only)
- Width: 60mm (including cushion nuts)
- Height: 50mm (square body cross-section)
Ultra-slim profile cylinder (30% thinner than standard models) with precision-adjustable cushioning mechanism. Features dual-piston design for smooth operation and integrated magnetic sensor slots (non-inductive model as standard). The 20B variant includes 4xM5 tapped holes on mounting faces for rigid installation. Compatible with Auto Switch series sensors for position feedback.
- High-density automation cells in electronics assembly
- Medical device actuation requiring precise stroke control
- Packaging machinery with space constraints
- Robotic end-effector tooling
- Semiconductor handling systems
Installation tip:
Use alignment jigs during mounting to prevent rod sideload. For vertical installations,
add 0.5mm shim adjustment for thermal expansion. Lubricate with ISO VG32 hydraulic oil
during maintenance cycles.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-20B |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
