Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-20S
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-20S Adjustable Thin Cylinder Specifications
- Series: ACQJ50~63 (Compact Adjustable Series)
- Model: ACQJ50X100-20S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50mm
- Stroke: 100mm (adjustable via external stopper)
- Buffer type: Fixed + external adjustable cushioning
- Operating pressure: 0.15–0.8 MPa
- Port size: M5×0.8 (two ports)
- Mounting style: Basic front flange (NF) with accessory options
- Tube material: Aluminum alloy hard oxidation
- Piston rod material: SUS304 stainless steel
- Rod end type: Female thread (M10×1.25)
- Operating temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP65 (standard dust/water resistance)
- Weight: 1.8kg ±3% (excluding accessories)
- Dimensions: 200mm(L) × 63mm(W) × 63mm(H)
- Stroke adjustment range: 0-20% of nominal stroke (0-20mm in this model)
- Lubrication: Pre-lubricated (Non-re-lubrication design)
Ultra-slim profile cylinder (40% thinner than standard models) with integrated stroke adjustment mechanism. Features dual cushioning system combining fixed internal buffers and external screw-type stroke limiters. The anodized aluminum construction ensures corrosion resistance while maintaining lightweight performance (30% weight reduction vs conventional cylinders). Includes magnetic piston for sensor mounting compatibility.
- Space-constrained automation equipment (3C electronics assembly lines)
- Precision clamping fixtures in CNC machining centers
- Web tension control systems in printing machinery
- Food packaging machines requiring frequent stroke adjustments
- Medical device actuation systems with hygiene requirements
Installation note:
When adjusting stroke length, ensure the lock nut is fully tightened after positioning.
Maximum side load capacity: 30N at full extension. For vertical installations,
use guide mechanisms if lateral forces exceed 15N. Lubricate adjustment threads
with ISO VG32 hydraulic oil annually.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-20S |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
