Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-20SB
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-20SB Adjustable Compact Cylinder Specifications
- Series: ACQJ50~63 (50mm/63mm bore sizes)
- Full model: ACQJ50X100-20SB
- Bore size: 50mm
- Stroke: 100mm (adjustable cushion)
- Operating pressure: 0.05~0.9 MPa
- Buffer type: External adjustable rubber cushion
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard), optional NPT1/8
- Mounting type: 20SB (basic front flange with foot mounting)
- Piston speed: 50~800 mm/s
- Rod material: Chrome-plated carbon steel (S45C)
- Cylinder tube: Aluminum alloy anodized finish
- Seal material: NBR (nitrile rubber)
- Weight: 1.63 kg (with standard accessories)
- Dimensions:
- Total length: 205mm (stroke 100mm + end caps)
- Width: 70mm (mounting flange to rod end)
- Height: 61mm (including mounting foot)
- Rod diameter: 16mm
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (DOP oil)
Ultra-slim profile cylinder with 23% reduced height compared to standard models, featuring dual-side adjustable cushioning for precise stroke-end control. The 20SB mounting configuration provides stable fixed-centerline installation. Precision honed tube ensures ≤0.2mm/m straightness deviation. Includes magnetic piston for position sensing compatibility.
- High-density automation cells with space constraints
- PCB handling robots in electronics manufacturing
- Medical device assembly lines requiring smooth actuation
- Packaging machinery with frequent stroke adjustments
- Cleanroom environments (optional stainless steel version)
Installation tip:
When using adjustable cushion, turn screws clockwise to increase damping force.
Maximum allowable lateral load: 35N. Lubricate rod every 2,000km of cumulative travel.
- 40μm filtration recommended
- Use ISO VG32 hydraulic oil for lubrication if required
- Maximum permissible sway angle: ±3°
- Breakaway pressure: ≤0.08MPa
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-20SB |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
