Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-30
$82.31
Regular price
$89.81
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQJ50X100-30
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQJ50~63 Adjustable Compact Cylinder
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
Installation tips:
Lubricate with ISO VG32 hydraulic oil mist. For vertical mounting,
install rod end downward to prevent seal wear. Maintain 0.3mm minimum
clearance between magnet and sensor. Cushion adjustment requires
1/8" hex key (included).
Critical note:
Avoid side load exceeding 15N. Use floating joints when misalignment
exceeds 0.5°. Maximum permissible lateral play: ±0.2mm. Requires
40μm filtered air with dew point -15℃ below ambient.
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-30 Adjustable Compact Cylinder Specifications
- Series: ACQJ50~63 (50mm/63mm bore options)
- Full model: ACQJ50X100-30
- Bore size: 50mm (1.97")
- Stroke: 100mm (3.94")
- Action type: Double-acting with adjustable cushioning (both ends)
- Operating pressure: 0.05~0.9 MPa (7~130 PSI)
- Max theoretical thrust: 177kgf @0.63MPa
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Piston speed: 50~800mm/s (with cushion adjustment)
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Seal material: Polyurethane + NBR seals
- Body material: Anodized aluminum alloy
- Mounting type: Basic axis mount (ISO 15552 compatible)
- Weight: 1.82kg (4.01 lbs)
- Dimensions: 50mm(W) × 50mm(H) × 188mm(L) (body only)
- Full extended length: 288mm (body + stroke)
- Protection rating: IP54 (standard)
Ultra-slim profile cylinder (30% thinner than standard models) featuring dual adjustable rubber cushions for precise end-position control. The chrome-plated piston rod with integrated magnet enables position sensing compatibility. Optimized for high-cycle applications with its wear-resistant guide band design.
Typical Applications:
- PCB handling robots in electronics manufacturing
- Precision clamping devices in CNC machining centers
- Vertical lift mechanisms in packaging lines
- Medical device assembly automation
- Solar panel positioning systems
Installation tips:
Lubricate with ISO VG32 hydraulic oil mist. For vertical mounting,
install rod end downward to prevent seal wear. Maintain 0.3mm minimum
clearance between magnet and sensor. Cushion adjustment requires
1/8" hex key (included).
Critical note:
Avoid side load exceeding 15N. Use floating joints when misalignment
exceeds 0.5°. Maximum permissible lateral play: ±0.2mm. Requires
40μm filtered air with dew point -15℃ below ambient.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-30 |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
