Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-30B
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-30B Adjustable Compact Cylinder Specifications
- Series: ACQJ50~63 (50mm/63mm bore options)
- Full model: ACQJ50X100-30B
- Bore size: 50mm
- Stroke: 100mm (adjustable ±2mm via external stopper)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning type: Adjustable rubber cushion (both ends)
- Mounting style: 30B (ISO 15552 standard center flange)
- Port size: M5x0.8 (dual ports on head/cap)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR seals with wear ring
- Weight: 1.23kg (without accessories)
- Dimensions: 200mm(L) × 63mm(W) × 56mm(H)
- Max theoretical force: 157N @0.5MPa
- Speed range: 50–750mm/s
Ultra-slim profile cylinder (25% thinner than standard models) with external stroke adjustment capability. Features corrosion-resistant construction and dual cushioning adjustment screws for precise end-position control. Includes auto switch grooves for sensor mounting (inductive sensors sold separately).
- Space-constrained automation: PCB handling robots
- Precision positioning in semiconductor wafer stages
- Medical device actuation systems
- High-cycle packaging machine pushers
- Vertical lift mechanisms in cleanroom environments
Installation tip:
Use alignment jig when mounting to ensure parallel rod movement.
Lubricate with ISO VG32 hydraulic oil during maintenance.
Avoid side loads exceeding 30N for optimal seal life.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-30B |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
