Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-30S
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50~63 Adjustable Compact Cylinder ACQJ50X100-30S Specifications
- Series: ACQJ (Adjustable Compact Cylinder)
- Model Code: ACQJ50X100-30S
- Bore Size: 50mm (63mm max in series)
- Stroke: 100mm (adjustable via external stopper)
- Operating Pressure: 0.1–0.9 MPa
- Cushioning: Fixed rubber buffer + external adjustable stopper
- Port Size: 1/4" NPT (G1/8 optional)
- Mounting Type: Basic type (MF1) with SW50-30S switch bracket
- Piston Material: Aluminum alloy hard anodized
- Rod Material: Chrome-plated steel
- Seal Material: NBR (Nitrile rubber)
- Temperature Range: -20℃ to 80℃
- Weight: 1.5kg ±3% (with accessories)
- Dimensions: 180mm(L) × 50mm(W) × 50mm(H) (retracted position)
- Stroke Tolerance: ±1.5mm
- Max Theoretical Force: 176N @0.63MPa
- Lubrication: Pre-lubricated (DOP oil)
Ultra-slim profile cylinder (15% thinner than standard models) with external stroke adjustment mechanism. Features dual cushioning system and integrated magnetic sensor groove (compatible with SW50 series sensors). The corrosion-resistant construction includes IP54-equivalent sealing for dust/moisture protection.
- Space-constrained automation cells (electronics assembly)
- Precision clamping fixtures for CNC machining
- Vertical lift mechanisms in packaging lines
- Actuation in cleanroom environments (medical device manufacturing)
- Modular robotic end effectors
Installation Note:
Ensure 0.5-1mm clearance between adjustable stopper and cylinder body during stroke setting.
Lubricate sliding parts with ISO VG32 hydraulic oil monthly in high-cycle applications (>500 cycles/day).
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-30S |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
