Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-30SB
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50~63 Adjustable Compact Cylinder (ACQJ50X100-30SB) Specifications
- Series: ACQJ (Thin-profile adjustable stroke series)
- Full model: ACQJ50X100-30SB
- Bore size: Ø50mm (ACQJ50)
- Stroke: 100mm (adjustable through external stopper)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting type: Basic type with foot mounting (30SB code)
- Port size: Rc1/4 (G1/4 optional)
- Piston rod thread: M14×1.5
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: SUS304 stainless steel
- Seals: NBR (standard), optional FKM
- Weight: 2.45kg (excluding accessories)
- Dimensions:
- Body length: 176mm (excluding rod)
- Full extended length: 276mm (100mm stroke)
- Mounting foot span: 64mm (center-to-center)
- Height: 63mm (from base to top)
- Width: 76mm (mounting foot dimension)
- Protection class: IP54 (standard wiper seal)
Ultra-slim cylinder (30% thinner than standard models) with stroke adjustment mechanism using external stopper screws. Features dual adjustable pneumatic cushions for precise end-position control. The 30SB variant includes integrated mounting feet with vibration-resistant rubber pads. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Precision clamping in CNC tool changers
- Vertical lifting mechanisms in semiconductor handlers
- Part positioning in automated assembly lines
- Actuation in cleanroom-compatible machinery
- Packaging machine ejector systems
Installation tip:
Maintain 0.5-1mm clearance between stopper screws and cylinder ends during adjustment.
For vertical mounting, use anti-drop locknuts on piston rod threads. Lubricate every
3,000km of stroke travel using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-30SB |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
