Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-40
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50~63 Adjustable Compact Cylinder ACQJ50X100-40 Specifications
- Model Series: ACQJ50~63 (Cylinder bore 50mm-63mm)
- Specific Model: ACQJ50X100-40
- Bore Size: 50mm
- Stroke: 100mm (±0.5mm adjustment range)
- Type: Double-acting adjustable stroke thin cylinder
- Mounting Style: 40-series (Front flange with guide rod)
- Operating Pressure: 0.15-1.0 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Stroke Adjustment: Built-in hex wrench adjustment (±0.5mm)
- Port Size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Piston Rod Thread: M10x1.25
- Material: Aluminum alloy barrel, Chrome-plated piston rod
- Seal Material: NBR (Nitrile Rubber)
- Temperature Range: -20℃ to 80℃
- Protection Rating: IP54 (Standard)
- Accessories: Includes magnetic switch bracket (MSQG-5 compatible)
- Weight: 2.3kg (Excluding accessories)
- Dimensions (LxWxH): 210mm x 63mm x 63mm (Stroke extended)
Ultra-slim profile cylinder (25% thinner than standard models) with precision stroke adjustment capability via integrated mechanism. Features wear-resistant chromium piston rod and anti-rotation guide rods for precise linear motion. Pre-lubricated for maintenance-free operation up to 3,000km travel distance. Requires 40μm filtered dry air with ISO 8573-1:2010 class 4.4.3.
- PCB board clamping in SMT manufacturing
- Precision positioning in semiconductor handling robots
- Compact packaging machine ejectors
- Medical device actuation systems
- 3-axis gantry system tool changers
Installation Tips:
Maintain parallel alignment of guide rods during mounting. For stroke adjustment:
1) Loosen lock nut 2) Turn adjustment screw (1 rotation ≈ 0.5mm stroke change)
3) Tighten nut to 0.7-1.0N·m torque. Use C-rings (included) for stroke limitation.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-40 |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
