Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-40B
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-40B Adjustable Compact Cylinder Specifications
- Series: ACQJ50~63 (50mm-63mm bore size range)
- Full model: ACQJ50X100-40B
- Bore size: 50mm (±0.13mm tolerance)
- Stroke: 100mm (adjustable with stopper)
- Operating pressure: 0.1~0.9 MPa
- Cushioning: Adjustable air cushion (front/rear)
- Mounting types: Basic type (MF1), foot-mounted (MP4), or front flange (MFF)
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Piston speed: 50~800 mm/s (optimal at 500 mm/s)
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy cylinder tube, CR12MoV piston rod
- Seals: NBR (standard), FKM optional
- Weight: 1.2kg (excluding accessories)
- Dimensions: 200mm(L) × 63mm(W) × 63mm(H) (at full extension)
- ISO standard: 6432 compliant
- Protection class: IP65 (wipers included)
Ultra-slim profile cylinder (40% thinner than standard models) with built-in stroke adjustment mechanism. Features dual piston seals for leak prevention and magnetic version compatibility (suffix -M for sensor mounting). Ideal for high-speed applications requiring precise end-position control.
- PCB handling robots in electronics manufacturing
- Clamping mechanisms in CNC tool changers
- Cartesian coordinate positioning systems
- High-speed sorting gates in logistics
- Medical device assembly automation
Installation tip:
Use alignment jigs during mounting to prevent side load. For vertical installations,
reduce operating pressure by 20% when supporting suspended loads. Lubricate with
ISO VG32 turbine oil if operating below 0.3 MPa.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-40B |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
