Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-40S
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50~63 Adjustable Compact Cylinder ACQJ50X100-40S Specifications
- Model Series: ACQJ50~63 (50mm/63mm bore sizes)
- Full Model Code: ACQJ50X100-40S
- Bore Size: 50mm
- Stroke: 100mm (adjustable via built-in stroke limiter)
- Operating Pressure: 0.05–1.0 MPa
- Port Size: G1/8 (NPT1/8 optional)
- Cushioning: Adjustable air cushion (both ends)
- Piston Speed: 50–700 mm/s
- Ambient Temperature: -20℃ to 80℃
- Body Material: Aluminum alloy (anodized)
- Rod Material: Chrome-plated carbon steel
- Seal Material: NBR/PU (standard), optional FKM
- Mounting: Front flange (ISO 15552 standard)
- Weight: 3.2kg (without accessories)
- Dimensions: 180mm(L) × 63mm(W) × 63mm(H)
- Repeat Positioning Accuracy: ±0.5mm
- Lubrication: Pre-lubricated (oil-free operation possible)
Ultra-slim profile cylinder (40% thinner than standard models) with precision stroke adjustment mechanism. Features dual anti-rotation guide rods for enhanced lateral load capacity. The chrome-plated piston rod incorporates a wear-resistant coating, supporting high-frequency cycles (up to 5 million strokes). Optional magnetic piston version available for position sensing.
- PCB handling robots in electronics manufacturing
- Precision clamping in CNC fixture systems
- Vertical lift mechanisms in packaging lines
- Door actuation in cleanroom environments
- Material sorting gates in logistics automation
Installation note:
Maintain ≤0.2mm alignment tolerance during mounting. For vertical installations exceeding 45° angle,
use rod-down orientation to prevent seal wear. Lubricate guide rods monthly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-40S |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
