Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-40SB
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50~63 Adjustable Compact Cylinder ACQJ50X100-40SB Specifications
- Model Series: ACQJ50~63 (50mm/63mm bore sizes)
- Specific Model: ACQJ50X100-40SB
- Type: Double-acting cylinder with adjustable cushioning
- Bore Size: 50mm (standard series includes 50/63mm options)
- Stroke: 100mm (customizable from 25-500mm)
- Operating Pressure: 0.05-0.9 MPa
- Operating Temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting Style: Front flange with magnetic switch slot (40SB code)
- Port Size: M5x0.8 (standard) or NPT1/8 optional
- Piston Rod Material: Hard chrome-plated steel
- Tube Material: Anodized aluminum alloy
- Seal Material: NBR (nitrile rubber)
- Weight: 1.25kg (bare cylinder without accessories)
- Dimensions:
- Body Length: 158mm (minimum retracted length)
- Total Stroke Length: 258mm (158mm + 100mm stroke)
- Width: 63mm (including mounting flange)
- Height: 50mm (bore diameter)
- Switch Compatibility: Compatible with D-A93 series magnetic sensors
- ISO Standard: Compliant with ISO 6432 (8mm rod diameter)
Ultra-slim profile cylinder (23% thinner than standard models) featuring precision-regulated deceleration control through its dual adjustable buffers. The 40SB variant includes pre-drilled mounting holes and sensor slots for simplified integration. Optimized for high-cycle applications with its low-friction seals and wear-resistant rod treatment. Requires 40μm filtered air and ISO VG32 hydraulic oil lubrication for optimal performance.
- PCB handling robots in electronics manufacturing
- Cartesian coordinate assembly systems
- Medical device clamping mechanisms
- High-speed sorting gates in logistics automation
- Precision glass panel pressing equipment
Installation protocol:
Maintain 0.5mm alignment tolerance during rail mounting. For vertical installations,
use model with air buffer locknuts tightened to 2.5N·m torque. Lubricate every
500km of cumulative stroke distance under continuous operation.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-40SB |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
