Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-50B
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-50B Adjustable Compact Cylinder Specifications
- Series: ACQJ50~63 (50mm/63mm bore size options)
- Full model: ACQJ50X100-50B
- Bore size: 50mm
- Stroke: 100mm
- Adjustable stroke range: ±5mm via external stopper
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (front/rear)
- Mounting type: Basic type (accessory brackets available)
- Port size: M5x0.8 (standard) / optional NPT1/8
- Piston material: Die-cast aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal material: NBR (standard) / optional FKM
- Weight: 1.25kg (with rod extension)
- Dimensions (L×W×H):
- Retracted: 175mm × 50mm × 50mm
- Extended: 275mm × 50mm × 50mm
Ultra-slim profile cylinder (50mm height) with precision stroke adjustment capability, featuring dual-side adjustable cushioning for controlled deceleration. The B-suffix model includes built-in magnetic sensor grooves (compatible with CS-L1 series sensors). Ideal for applications requiring space optimization without compromising force output (Max thrust: 196N at 0.5MPa).
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms in CNC tool changers
- Vertical lift systems in automated storage racks
- Packaging machine flap control systems
- Medical device positioning stages
Installation tip:
For optimal performance, maintain 0.5mm minimum clearance between adjustable stoppers and cylinder body during alignment. Lubricate with ISO VG32 hydraulic oil during initial installation.
Critical note:
Avoid lateral loading exceeding 30N·m. When used in vertical orientation, always install anti-rotation guides. Maximum permissible side load: 1/20 of piston thrust.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-50B |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
