Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-50S
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-50S Adjustable Compact Cylinder Specifications
- Series: ACQJ50~63 (50mm/63mm bore options)
- Full model: ACQJ50X100-50S
- Bore size: 50mm
- Stroke: 100mm ±0.5mm
- Mounting type: Fixed cushion (50S = square base with single rod)
- Operating pressure: 0.05~0.9 MPa
- Cushioning: Adjustable pneumatic cushion (external screw adjustment)
- Port size: M5x0.8 (G1/8 optional)
- Rod thread: M10x1.25
- Seal material: Polyurethane (NBR optional)
- Temperature range: -10℃ to 80℃
- Piston speed: 50~800 mm/s
- Weight: 1.45 kg (with rod)
- Dimensions:
- Length: 198mm (including cushion)
- Width: 50mm (square base)
- Height: 50mm (excluding rod)
- Rod protection: Chrome-plated (3-5μm thickness)
- ISO standard: 6432 (compact cylinder specification)
Ultra-slim profile cylinder (height ≤50mm) with space-saving design for modern automation systems. Features dual adjustable cushioning for precise end-position control and reduced impact noise. The anodized aluminum body ensures corrosion resistance in humid environments. Compatible with auto switches (magnetic sensor ready).
- PCB handling robots with tight vertical spacing
- Medical device clamping mechanisms
- Automotive window regulator testing equipment
- High-speed sorting gates in logistics systems
- Semiconductor wafer transfer modules
Installation tip:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
Use locknuts (not included) for position-sensitive applications. Lubricate through
air ports monthly in high-cycle operations (>500k cycles/year).
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-50S |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
