Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-75B
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50~63 Adjustable Compact Cylinder ACQJ50X100-75B Specifications
- Model Series: ACQJ50~63 (50mm/63mm bore sizes)
- Specific Model: ACQJ50X100-75B
- Bore Size: 50mm
- Stroke: 100mm ±0.5mm (adjustable)
- Mounting Type: Fixed-shaft adjustable (75B indicates base-mounted)
- Operating Pressure: 0.05~0.9 MPa
- Cushioning: Adjustable pneumatic cushion (dual-side)
- Port Size: M5x0.8 (standard) / NPT1/8 optional
- Temperature Range: -20℃ to 80℃
- Piston Material: Aluminum alloy with hard anodization
- Rod Material: Chrome-plated steel (Cr-Mo)
- Seal Type: NBR seals (standard) / FKM optional
- Weight: 1.8kg ±5% (with accessories)
- Dimensions:
- Length: 194mm (full extension)
- Width: 63mm (mounting base width)
- Height: 63mm (including cushion adjusters)
- Max Speed: 500-800mm/s (with cushion)
- Lubrication: Pre-lubricated (non-re-lube design)
Ultra-slim profile cylinder (25% thinner than standard models) with precision stroke adjustment via micrometer-style mechanical stops. Features wear-resistant rod guides and dual anti-rotation shafts for stable linear motion. The 75B variant includes integrated mounting bosses for rigid base fixation.
- Precision clamping in CNC tool changers
- Vertical lifting in PCB handling robots
- Gate positioning in plastic injection molding
- Workpiece ejection in high-speed presses
- Valve actuation in cleanroom equipment
Installation tip:
Align cushion adjustment screws perpendicular to motion axis.
For stroke adjustment, loosen lock nut and rotate stopper (1 full rotation = 1mm stroke change).
Maintain 0.5mm minimum residual stroke.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-75B |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
